Naviate HVAC & Plumbing
Accelerate project documentation and optimize working methods with built-in standards for HVAC and Plumbing engineers to enhance your BIM workflow.
FEATURES OF NAVIATE HVAC & PLUMBING
Step
Quick and easy way to route pipes, cable trays and ducts-up, down or sideways. Choose a start and end point or combine with an obstacle you want to avoid, and you'll get a new suggestion. Post this as a shortcut and you will save a lot of time!
Connect (Duct/Pipe)
Connect to an air terminal or sprinkler head by clicking on an existing pipe/line followed by the desired destination. Choose different types of angles and start with several parts in sequence for increased efficiency.
Split Duct/Pipe
Split sections of duct or pipe segments at a customised interval, in seconds. Select the duct/pipe you want to split and click on the function, that's all it takes!
